Connecting to the Network
Enterasys B5 Gigabit Ethernet Switch Hardware Installation Guide 2-29
Removing an SFP/10G Transceiver
Toremoveatransceiverfroma portslot,referbacktoFigure 2‐19onpage 2‐28andproceedas
follows:
1. Withanantistaticwriststrapattachedtoyourwrist,removethecablesconnectedtothe
transceiver.
2. Releasethetransceiverusingitswirehandle.Specificoperationandlocationofthehandlewill
vary
dependingontransceivertype.
3. Graspthesidesofthetransceiverandpullitstraightoutoftheportslot.
IfstoringorshippinganSFP/10G,whichhasafiber‐opticconnector,insertitsprotectivedust
covertoprotecttheendsofthefiber‐opticfibersfromdustorcontamination.
Connecting Fiber-Optic Cables to SFP/10G Ports
BeforeconnectingcablestoSFP/10Gports,youmustinstalltheappropriatetransceiveras
describedin“InstallinganOptionalSFP/10GTransceiver”onpage 2 ‐27.Thissectiondescribes
howtoconnecta1‐or10‐Gigabitfiber‐opticsegmentfromthenetworkorotherdevicestoanSFP
or10Gportconnector
(LCorMT‐RJ).
Eachfiber‐optic linkconsistsoftwofiber‐opticstrandswithinthecableforTransmit(TX)and
Receive(RX).Thetransmitstrandfromadeviceportconnectstothereceiveportofafiber‐optic1‐
/10‐GigabitEthernetdeviceattheotherendofthesegment.
Thereceivestrandofthe applicable
LCorMT‐RJportconnectstothetransmitportofthefiber‐optic1‐/10‐GigabitEthernetdevice.
Caution: Do NOT remove the SFP/10G from the port slot without releasing it. The SFP/10G is
released by pulling down on its wire handle. Attempting to remove the SFP/10G without releasing it
can damage the SFP/10G.
The SFP/10G and its host switch are sensitive to static discharges. Use an antistatic wrist strap and
observe all static precautions during this procedure. Failure to do so could result in damaging the
SFP/10G or host switch. Always leave the SFP/10G in the antistatic bag or an equivalent antistatic
container when not installed.
Precaución: NO quite el SFP/10G de la ranura sin antes abrir la traba ubicada en la parte frontal
del SFP/10G. Si lo hace, puede dañar el SFP/10G, puesto que es muy sensible a las descargas de
electricidad estática, al igual que el dispositivo host. Utilice la pulsera antiestática y tome todas las
precauciones necesarias durante este procedimiento. Si no lo hace, pude dañar el SFP/10G o el
dispositivo host. Mientras no esté instalado, mantenga el SFP/10G en su bolsa antiestática o en
cualquier otro recipiente antiestático.
Caution: Do not touch the ends of the fiber-optic strands, and do not let the ends come in contact
with dust, dirt, or other contaminants. Contamination of cable ends causes problems in data
transmissions. If the ends of the fiber-optic strands become contaminated, use a canned duster to
blow the surfaces clean. A fiber-port cleaning swab saturated with optical-grade isopropyl alcohol
may also be used to clean the ends.
Precaución: No toque los extremos de los cables de fibra óptica y evite su contacto con el polvo,
la suciedad o con cualquier otro contaminante. Si los extremos de los cables se ensucian, es
posible que la transmisión de datos se vea afectada. Si nota que losextremos de los cables de
fibra óptica se ensucian, utilice aire comprimido paralimpiarlos. También puede limpiarlos con un
estropajo embebido en alcohol isopropílico.
