Enterasys I-Series Hardware Installation Guide 2-1
2
Installation
This chapter describes power source and environmental requirements, and contains instructions
on setting up the I-Series switch.
Equipment needed:
• Phillips screwdriver
• Flat blade screwdriver
• Needle-nosed pliers
Follow the order of the sections below for correct installation.
Electrical Hazard: Only qualified personnel should install or service this unit.
Riesgo Eléctrico: Nada mas personal capacitado debe de instalar o darle servicio a esta unida.
Elektrischer Gefahrenhinweis: Installationen oder Servicearbeiten sollten nur durch
ausgebildetes und qualifiziertes Personal vorgenommen werden.
For information about... Refer to page...
Checking Environmental and Power Requirements 2-2
Special Considerations for Safe Use 2-4
Unpacking the I-Series Switch 2-5
Changing Alarm Relays from Normally Closed to Normally Open 2-6
Installing a Second IOM 2-7
Mounting the Switch 2-11
Connecting Power to the Switch 2-19
Connecting the Relays 2-22
Connecting to the Console Port 2-23
Connecting to the Network 2-24
Installing and Removing a Memory Card 2-31
Securing the IOM Cables 2-34
Completing the Installation 2-35
