Relay Specifications
Enterasys I-Series Hardware Installation Guide A-5
Relay Specifications
The specifications for each relay are as follows:
Mini-GBIC Input/Output Specifications
The Mini-Gigabit Ethernet Card (Mini-GBIC) port interface slots can support 1-Gbps fiber-optic
and copper connections.
For the latest information about pluggable transceivers available from Enterasys, see
http://www.enterasys.com/products/transceivers-ds.pdf
Industrial-Use Mini-GBICs
The following Mini-GBICs are rated for use in industrial or hazardous environments. These
Mini-GBICs can operate in temperatures between -40
o
to +60
o
C.
Table A-12 Relay Specifications
Item Specification
Maximum switching current 1 A
Maximum switching voltage 125 VDC
150 VAC
Maximum switching capacity 30 W, 60 VA
UL/CSA ratings 30 VDC / 1 A
65 VDC / 0.46 A
150 VAC / 0.46 A
Insulation resistance at 500 VDC > 10
9

Dielectric test voltage (1 min)
between coil and contacts
between open contacts
1500 Vrms
500 Vrms
Surge voltage resistance
according to Bellcore TR-NWT-00 1089 (2 / 10 s)
• between coil and contacts
• between open contacts
according to FCC 68 (10 / 160 s)
• between coil and contacts
• between open contacts
2500 V
2500 V
1500 V
1500 V


Table A-13 Industrial Mini-GBIC Input/Output Port Specifications
Item Specification
I-MGBIC-GSX Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard and has an LC connector. Requires SFP retention
bracket (850A0102-04-N), which is mounted on the I-Series chassis at
shipment.
