Installing and Removing a Memory Card
2-32 Installation
Installing a Memory Card
Refer to Figure 2-23 on page 2-33 as you perform the following procedure. This procedure
assumes that no memory card is currently installed.
To install a memory card:
1. If necessary, on the I3H-6TX-MEM, remove the cable retention bracket in order to access the
memory card slot coverplate.
2. Remove the two screws holding the memory card slot coverplate and remove the coverplate.
Save the two screws.
3. Slide the memory card into the slot and press firmly to seat the card into the connector. The
memory card is keyed so it will fit into the slot only one way.
4. Replace the coverplate and reinsert the screws. The coverplate has a knob that allows the plate
to be installed only one way.
5. If necessary, replace the cable retention bracket.
Table 2-3 Memory Card LED Definitions
LED Display Status
Power (PWR) Solid green Power is applied to slot. Do not remove card.
Off Power is not applied to slot, card may be removed.
Activity (ACT) Blinking or solid red Card is being accessed. Do not remove.
Off Card is idle and may be removed.
Note: The I-Series memory card is not interchangeable with a standard Compact Flash card. A
standard Compact Flash card will not work in the I-Series switch, and the I-Series memory card
cannot be used in place of a Compact Flash card in other systems.
Warning: Do not install or remove the memory card or the memory card cover unless the area is
known to be non-hazardous.
Advertencia: No instale ni retire la tarjeta de memoria o la cubierta de ésta a menos que esté
seguro de que el área no es peligrosa.
Warnhinweis: Die Speicherkarte bzw. die Abdeckung der Speicherkarte darf weder installiert noch
entfernt werden, es sei denn, die Umgebung gilt als ungefährlich.
Note: The coverplate must be reinstalled over the memory card slot for the memory card to
function.
