Page #62 background imageLoading...
Page #62 background image
1G694-13 Specifications
A-2 Specifications
A.1 1G694-13 SPECIFICATIONS
Table A-1 provides the I/O ports, processors and memory, physical, and environmental module
specifications for the 1G694-13.
Table A-1 1G694-13 Specifications
Item Specification
Ports
Ports 1 through 8 Eight fixed, 1000BASE-SX compliant MT-RJ ports
Ports 9 through 12 Four Mini-GBIC port slots for 1000BASE-SX or -LX
compliant Mini-GBICs
Port Interface Option Slot Supports one optional 10-Gigabit Ethernet expansion
module
Processors/Memory
Processors MPC8240, 200 MHz processor
Dynamic Random Access Memory
(DRAM)
64 MB
FLASH Memory 8 MB
Physical
Dimensions 6.6H x 43.8W x 38.73D (cm)
2.62H x 17.25W x 15.25D (in.)
Approximate Weight Gross: 8.05 kg (17.7 lb)
(shipping carton containing one device)
Net: 2.89 kg (6.4 lb) (one device without packaging)
MTBF (Predicted) 41,658 hours
Environmental
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -30°C to 73°C (-22°F to 164°F)
Operating Relative Humidity 5% to 90% (non-condensing)
