RJ45 COM Port Pinout Assignments
Specifications A-9
A.6 RJ45 COM PORT PINOUT ASSIGNMENTS
The COM port is a serial communications port that supports Local Management. Table A-17 shows
the COM port pin assignments.
A.7 REGULATORY COMPLIANCE
The 1G694-13 meets the safety and electromagnetic compatibility (EMC) requirements listed in
Table A-18:
Table A-17 Console Port Pin Assignments
Pin Signal Name Input/Output
1 Transmit Data (XMT) Output
2 Clear to Send (CTS) Input
3 Data Set Ready (DSR) Input
4 Receive Data (RCV) Input
5 Signal Ground (GND) NA
6 Request to Send (RTS) Output
7 Data Terminal Ready (DTR) Output
8 Data Carrier Detect (DCD) Input
Table A-18 Compliance Standards
Regulatory Compliance Standards
Safety UL 60950, CSA C22.2 No. 60950, 73/23/EEC,
EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10.
Electromagnetic Compatibility (EMC) 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC,
EN 55022, EN 61000-3-2, EN 61000-3-3,
EN 55024, AS/NZS CISPR 22, VCCI V-3.
