Input/Output Specifications for the 10GBASE-LR
A-4 Specifications
A.3 INPUT/OUTPUT SPECIFICATIONS FOR THE 10GBASE-LR
The ZPIM1-06 option slot supports XENPAK 10-Gigabit Ethernet (GbE) standard (802.3ae)
interface plug-in modules. These modules are hot swappable. Table A-4 through Table A-6 provide
the specifications for the 10GBASE-LR module, which is the only module available as of the
printing of this manual.
Warning: The 10GBASE-LR uses Class 1 lasers. Do not use optical instruments to view the laser
output. The use of optical instruments to view laser output increases eye hazard. When viewing
the output optical port, power must be removed from the network adapter.
Advertencia: No se debe usar instrumentos opticos para ver la potencia laser. El uso de los
instrumentos opticos para ver la potencia laser incrementa el riesgo a los ojos. Cuando vean el
puerto de la potencia optica, la corriente debe ser removida del adaptador de la red.
Warnhinweis: Benutzen sie keinesfalls optische Hilfmittel, um die Funktion des Lasers zu
überprüfen. Solche Hilfsmittel erhöhen die Gefahr von Sehschäden. Wenn sie den optischen Port
überprüfen möchten stellen Sie sicher, dass die Komponente von der Spannungsversorgung
getrennt ist.
Table A-4 Port Input/Output Specifications
Item Specification
10GBASE-LR Provides one SC fiber optic single-mode port that is
compliant with the 10 GbE standard SC connector.
Table A-5 10GBASE-LR Optical Specifications
Item 10 µm MMF
Transmit Power (minimum) -9.5 dBm
Receive Sensitivity -20 dBm
Link Power Budget 10.5 dBm
Table A-6 10GBASE-LR Operating Range
Item Modal Bandwidth @ 1300 nm Range
10 µm SMF N/A 2-10,000 Meters
