ZPIM1-01/ZPIM1-06, 10-Gigabit Port Interface Specifications
Specifications A-3
A.2 ZPIM1-01/ZPIM1-06, 10-GIGABIT PORT INTERFACE SPECIFICATIONS
As of the printing of this manual, two expansion modules (ZPIM1-01 and ZPIM1-06) were
available from Enterasys Networks. Table A-2 and Table A-3 provide the specifications.
Warning: The ZPIM1-01 uses Class 1 lasers. Do not use optical instruments to view the laser
output. The use of optical instruments to view laser output increases eye hazard. When viewing
the output optical port, power must be removed from the network adapter.
Advertencia: No se debe usar instrumentos opticos para ver la potencia laser. El uso de los
instrumentos opticos para ver la potencia laser incrementa el riesgo a los ojos. Cuando vean el
puerto de la potencia optica, la corriente debe ser removida del adaptador de la red.
Warnhinweis: Benutzen sie keinesfalls optische Hilfmittel, um die Funktion des Lasers zu
überprüfen. Solche Hilfsmittel erhöhen die Gefahr von Sehschäden. Wenn sie den optischen Port
überprüfen möchten stellen Sie sicher, dass die Komponente von der Spannungsversorgung
getrennt ist.
Table A-2 ZPIM1-01/ZPIM1-06 Port/Environmental Specifications
Item Specification
ZPIM1-01 Port
ZPIM1-06 Port
10-Gigabit Ethernet with a standard duplex SC connector.
10-Gigabit Ethernet option slot for XENPAK-compliant devices.
Environmental
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -30°C to 73°C (-22°F to 164°F)
Operating Relative Humidity 5% to 90% (non-condensing)
Table A-3 ZPIM1-01 Optical Specifications
Parameter Data Rate Minimum Maximum Units
Fiber Length – 62.5 installed
(160MHz/km)
4 x 3.1875 2 80 m
Fiber Length – 50 micron standard
(500MHz/km)
4 x 3.1875 2 250 m
Fiber Length – 50 micron
(850 optimized, 2200MHz/km)
4 x 3.1875 2 550 m
