Gigabit Ethernet Specifications
Specifications A-7
A.5.3 MGBIC-LC09 Specifications (1000BASE-LX)
A.5.4 MGBIC-08 Specifications (1000BASE-ELX)
Table A-12 MGBIC-LC09 Optical Specifications
Item 62.5 µm MMF 50 µm MMF 10 µm MMF
Transmit Power (minimum) -11.5 dBm -11.5 dBm -9.5 dBm
Receive Sensitivity -20 dBm -20 dBm -20 dBm
Link Power Budget 8.5 dBm 8.5 dBm 10.5 dBm
Table A-13 MGBIC-LC09 Operating Range
Item Modal Bandwidth @ 1300 nm Range
62.5 µm MMF 500 MHz/km 2-550 Meters
50 µm MMF 400 MHz/km 2-550 Meters
50 µm MMF 500 MHz/km 2-550 Meters
10 µm SMF N/A 2-10,000 Meters
Table A-14 MGBIC-08 Optical Specifications
Item
Transmit Power (minimum) -0 dBm, min. +2 dBm, typical +5 dBm, max.
Receive Sensitivity -24 dBm, min. -26 dBm, typical
Maximum Input Power -3 dBm
Link Power Budget
1
(Full Duplex Only)
1. The maximum drive distance (up to 70 km) depends on the quality of the installed single-mode fiber-optic
cable segment. Use the Link Power Budget to calculate the maximum cable length of the attached segment.
The Link Power Budget must not exceed those specified in this table. The MGBIC-08 input power must not
exceed -3 dBm. Otherwise, saturation could occur.
23 dB 28 dB, typical
