Mini-GBIC Input/Output Specifications
Specifications A-5
A.4 MINI-GBIC INPUT/OUTPUT SPECIFICATIONS
The Mini-Gigabit Ethernet Card (Mini-GBIC) port interface slots can support 1-Gbps fiber-optic
and copper connections as described in Table A-7. The optional Mini-GBICs are hot swappable.
A.5 GIGABIT ETHERNET SPECIFICATIONS
The following specifications for the Mini-GBICs (shown in Table A-8 through Table A-16) meet or
exceed the IEEE 802.3z-1998 standard.
A.5.1 MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)
Table A-7 Mini-GBIC Input/Output Port Specifications
Item Specification
MGBIC-LC01 Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC connector.
MGBIC-LC03 Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC duplex style connector.
MGBIC-LC09 Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-LX standard LC connector.
MGBIC-MT01 Provides one MT-RJ fiber-optic multi-mode port that is compliant with
the 1000BASE-SX standard MT-RJ connector.
MGBIC-08 Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-ELX standard LC connector.
MGBIC-02 Provides one RJ45 copper connection that is compliant with the
1000BASE-T standard RJ45 connector.
Table A-8 MGBIC-LC01 / MGBIC-MT01 Optical Specifications
Item 62.5 µm MMF 50 µm MMF
Transmit Power (minimum) -9.5 dBm -9.5 dBm
Receive Sensitivity -17 dBm -17 dBm
Link Power Budget 7.5 dBm 7.5 dBm
