If you are having a problem with the projector, first check the projector's indicators and see "Reading the Indicators".

See the following if the indicators do not show clearly what the problem might be.

s "When the Indicators Provide No Help" p.145

Reading the Indicators

The projector is provided with the following four indicators. The color and lit status of the indicators shows the status of the projector.

Power indicator Indicates the projector's status.

Status indicator Indicates the projector's status.

Lamp indicator Indicates the projection lamp status.
