Signal Refresh Rate (Hz) Resolution (dots)

SVGA 60 800x600

XGA 60 1024x768

WXGA 60 1280x800

60 1366x768

WXGA+ 60 1440x900

WXGA++ 60 1600x900

WSXGA+

60 1680x1050

SXGA

60 1280x960

60 1280x1024

SXGA+ 60 1400x1050

UXGA 60 1600x1200

SDTV (480i/480p) 60 720x480

SDTV (576i/576p) 50 720x576

HDTV (720p) 50/60 1280x720

HDTV (1080i) 50/60 1920x1080

HDTV (1080p) 24/30/50/60 1920x1080

* EB-585Wi/EB-585W/EB-575Wi/EB-575W only

MHL Input Signal

Signal Refresh Rate (Hz) Resolution (dots)

VGA 60 640x480

SDTV (480i/480p) 60 720x480

SDTV (576i/576p) 50 720x576

HDTV (720p) 50/60 1280x720

HDTV (1080i) 50/60 1920x1080

HDTV (1080p) 24/30 1920x1080
