Connecting External Equipment

You can output images and audio by connecting an external monitor or speaker.

When outputting images to an external monitor

Connect the external monitor to the projector's Monitor Out port using the cable supplied with the external monitor.

When outputting audio to an external speaker

Connect the external speaker to the projector's Audio Out port using a commercially available audio cable.

Connecting Equipment
