Pen Tray (EB-585Wi/EB-575Wi only)

Name Function

Fixing points

Attach the pen tray to a whiteboard or wall.

Security hole

Pass a commercially available lock through here.

It is recommended that the pen tray be tightened with two

commercially available M5 bolts.

Part Names and Functions
