The port name, location, and connector orientation differ depending on the source being connected.
Connecting a Computer
To project images from a computer, connect the computer using one of the following methods.
AB
When using the optional computer cable
Connect the computer's display output port to the projector's Computer1 or Computer2 port.
You can output audio from the projector's speaker by connecting the computer's audio output port to the projector's Audio1 or Audio2 port using a commercially available
audio cable.
C
When using the supplied or a commercially available USB cable
Connect the computer's USB port to the projector's USB-B port.
Audio from the computer is output from the projector with the projected image.
D
When using a commercially available HDMI cable
Connect the computer's HDMI port to the projector's HDMI1/MHL or HDMI2 port.
Audio from the computer is output from the projector with the projected image.
Connecting Equipment
28
