• You can also set the port used for audio input from the Configuration menu.
s Extended - A/V Settings - Audio Output p.123
• When projecting an image source connected to the Monitor Out/Computer2 port, set the Monitor Out Port to Computer2 from the Configuration menu.
s Extended - Operation - Monitor Out Port p.123
• If audio is not output when an HDMI cable is connected, connect a commercially available audio cable to the Audio Input port. After connecting the cable, select
the Audio Input port you connected to from HDMI1 Audio Output or HDMI2 Audio Output from the Configuration menu.
s Extended - A/V Settings - HDMI1 Audio Output/HDMI2 Audio Output p.123
• If the source you want to connect to has an unusually shaped port, use the cable supplied with the device or an optional cable to connect to the projector.
• When using a commercially available 2RCA(L/R)/stereo mini-pin audio cable, make sure it is labeled "No resistance".
Connecting Equipment
33
