Category Item Status Display Explanation
Signal Information 5V Detection Detected Displays the detection results of 5V signals.
Not Detect
TMDS Clock - Displays the TMDS frequency of the current input signal.
TMDS H-Frequency - Displays the horizontal frequency of the current input signal.
TMDS V-Frequency - Displays the vertical frequency of the current input signal.
DetChg 5CFHMP123 - Displays the factors of signal changes.
Stable Time - Displays the operating time since the input source is determined.
HDCP Status Non-HDCP Displays the HDCP status.
Passed
Failed
HDCP Ver - Displays the HDCP version.
AVI Info VIC - Displays the VIC information (AVI) of the current input signal.
AVI InfoChecksum OK Displays the checksum result for AVI.
NG
Signal Mode HDMI Displays the signal mode.
DVI
Pixel Encoding RGB Displays the color space information (AVI) of the current input signal.
YUV4:4:4
YUV4:2:2
YUV4:2:0
HDBaseT Level - You can display the image signal information from the HDBaseT port.
a
Items displayed for Signal Information vary depending on the model being used and the image signal and source being projected.
Reading Status Monitor
160
