Category Item Status Display Explanation
Source Video Signal - Displays the current input video signal.
Color Space RGB Displays the color space of the current input signal.
YCbCr
YPbPr
H-Frequency - Displays the horizontal frequency of the current input signal.
V-Frequency - Displays the vertical frequency of the current input signal.
Sync Polarity H:Posi / V:Posi Displays the Sync polarity.
H:Posi / V:Nega
H:Nega / V:Posi
H:Nega / V:Nega
Sync Mode Composite Sync Displays the sync type.
Separate Sync
Sync On Green
Detected Mode - Displays the discriminant resolution of the current input signal.
Video Level Auto (Normal) Displays the video level of the projector.
Auto (Expanded)
Normal
Expanded
a
Items displayed for source vary depending on the model being used and the image signal and source being projected.
Reading Status Monitor
159
