4-22
EMP-TW1000
SEIKO EPSON Revision:A
3. Remove the five screws (C.C.SCREW, 3x6, F/ZN-3C) that secure the MA Ground Plate,
and remove the MA Ground Plate.
Figure 4-18.
Plate, Ground, MA
