Epson FX-2180 Service Manual

FX-2180 Service Manual Product Descriptions
Rev. A
1-
6
 Roll paper
Table 1-12. Paper Specification (Multi part sheet)
Front entry Rear entry
Min. Max. Minimum Maximum
Width (inch)
(mm)

8.5
216
Length (inch)
(mm)
 
Thickness
(inch)
(mm)

0.0028
0.07
0.0035
0.09
Weight (g/m
2
)
(lb)

52
14
82
22
Quality

Plain paper
Not curled / Not folded /
Not crumpled
INTERFACE
Standard Bi-directional parallel interface
(IEEE-1284 nibble mode)
Option Type-B interface level 2
SOFTWARE SPECIFICATION
Control code ESC/P
IBM 2381 Plus Emulation
Fonts 2 LQ & 1 draft Bitmap typefaces
8 Barcode fonts
Character table Standard version 11 tables
NLSP version 20 tables
Input buffer 64 kB
ENVIRONMENT CONDITION
Temperature 5 - 35°C (Operation)
15 - 25°C (Recycled paper, envelope,
label or roll paper printing)
-30 - 60°C (Non-operation)
Humidity 10 - 80%RH (Operation)
30 - 60%RH (Recycled paper, envelope,
label or roll paper printing)
ELECTRICAL SPECIFICATION
120V version
Rated voltage AC120V
Input voltage range AC 99 - 132V
Rated frequency range 50 - 60Hz
Input frequency range 49.5 - 60.5Hz
Rated current 1.0A (max. 1.8A)
Power consumption Approx. 46W (ISO/IEC10561 Letter pattern)
Energy Star program compliant
Insulation resistance 10MΩ min. (AC line - Chassis, 500V)
Dielectric strength AC1000V rms 1 minute or
AC1200V rms 1 second (AC line - Chassis)
230V version
Rated voltage AC220 - 240V
Input voltage range AC 198 - 264V
Rated frequency range 50 - 60Hz
Input frequency range 49.5 - 60.5Hz
Rated current 0.5A (max. 0.9A)
Power consumption Approx. 46W (ISO/IEC10561 Letter pattern)
Energy Star program compliant
Insulation resistance 10MΩ min. (AC line - Chassis, 500V)
Dielectric strength AC1500V rms 1 minute (AC line - Chassis)
UPS (Universal Power Supply) version
Rated voltage AC100-120V / AC220 - 240V
Input voltage range AC90 - 132V / AC 198 - 264V
Rated frequency range 50 - 60Hz
Input frequency range 49.5 - 60.5Hz
Rated current 1.1A (max.1.8A) / 0.5A (max. 0.9A)
Power consumption Approx. 46W (ISO/IEC10561 Letter pattern)
Energy Star program compliant
Insulation resistance 10MΩ min. (AC line - Chassis, 500V)
Dielectric strength AC1500V rms 1 minute (AC line - Chassis)
