Micro Adjust ↑ / ↓
These switches are effective when the micro adjust function is enable
by Pause switch.
Micro Adjust function executes micro feed backward or forward by
1/216 inch.
TOF adjustment is enable in the TOF position after loading, and Tear-
off adjustment is enable in the Tear-off position.
1.2.1.2 Lamps
Pause (Orange)
It is on when the printer is in pause, and it is off when the printer is on
line condition.
It blinks when the Micro Adjust function is enabled or printhead is in
hot condition.
Paper Out (Red)
It is on when the printer is in the paper out condition, and it is off when
the paper is set in the printer.
Tear Off / Bin (Green)
Only right LED is on when CSF bin1 is selected.
Only left LED is on when CSF bin 2 is selected.
Both LEDs are on when Card mode is selected.
Both LEDs blink when continuous paper is in the Tear-Off position.
Both LEDs are off when continuous paper is out of the Tear-Off
position.
Font (Green)
The font LEDs consist of two LEDs. The current using font is shown by
these two LEDs on/ off combinations.
Pitch (Green)
The pitch LEDs consist of three LEDs. The current using pitch is shown
by these three LEDs on/ off combinations.
1.2.2 Buzzer
This printer makes buzzer sounds when it discover error or illegal condition,
as listed below:
Paper Out error
Approx.100ms buzzer sounds three times with two intervals of
approx.100ms.
Cover open error
Approx.100ms buzzer sounds three times with two intervals of
approx.100ms.
Release lever operation error
Approx.100ms buzzer sounds five times and approx.100ms interval is
four times.
Illegal panel operation
One approx.100ms buzzer sounds.
