Table 7-14. Connector Pin Alignments - CN15
Pin I/O Signal Name Function
1 I COPEN Case open sensor signal
2 O PAUSE Pause LED signal
3
+5V +5VDC
4 O POUTL Paper out LED signal
5 O RESRVL Pitch select LED signal
6 I PAUSSW Pause button signal
7 O TMIN2L Tear off / bin select signal
8 O TMIN1L Tear off / bin select signal
9 O PITC1L Pitch select LED
10 O PITC2L Pitch select LED
11
FONT3L Not connected
12 O FONT2L FONT LED signal
13 O FONT1L FONT LED signal
14
GND Signal ground
15
GND Signal ground
16 I FONTSW Font button signal
17 I PITCSW Pitch button signal
18 I TBINSW Tear off / bin signal
19 I PSC Operate button signal
20 I LDEJSW Load / Eject button signal
21 I LFFFSW LF / FF button signal
22
FG Frame ground
