Epson LQ 1050 - B/W Dot-matrix Printer - Home Position Sensor Removal

REV.-A
4.2.5.6
Step 1:
Step 2:
Step 3:
Step 4:
Home Position Sensor Removal
Remove the printer mechanism (Refer to Section 4.2.5. 1.).
Press the two tabs of the home position sensor on the bottom of the base frame.
Remove the home position sensor.
Disconnect the connector from the home position sensor.
Tab
Home Position Sensor
\
v
Connector
(a) Bottom View
(b) Top View
Figure 4-24. Home Position Sensor Removal
4-19
