Epson PowerLite 5000 Service Manual

EPSON PowerLite 5000 Service Manual
A-2
15-2 2023192 ELP5000 Speaker
15-3 1021795 Filter Board B Mounting Screw
15-4 1034025 Speaker Cushion
15-5 1034398 Speaker Holding Insulator Plate
16 1021795 Filter Board B Mounting Screw
17 1021795 Filter Board B Mounting Screw
18 3001779 Receptor Board Assembly B
19 1021795 Filter Board B Mounting Screw
20 1032053 Rear Case Block
20-1 1032054 Rear Case Unit
20-10 1033583 RCA Jack Conduction Plate
20-11 3001779 Receptor Board Assembly B
20-12 1033703 Connector Board Mounting Screw
20-2 3002195 Audio Board Assembly
20-5 1032057 Audio Board Shield Plate
20-6 1021824 Mounting Screw
20-7 1021795 Filter Board B Mounting Screw
20-8 1021824 Mounting Screw
20-9 1032367 Audio Board Radiation Spring
21 1033691 Cable Assembly G Mounting Screw
22 1032134 D Sub Mounting Screw (Hexagon)
25 1032071 Upper Case Block
26 1033707 Upper Case Block Mounting Screw
27 1034318 Upper Case Block Mounting Screw
28 1032080 Control Panel
29 1034329 Control Panel Spring
30 3002147 Remote Board Assembly
31 1032368 Remote Board Shield Plate
32 1032350 Remote Board Cover
33 1021795 Filter Board B Mounting Screw
34 1034713 Remote Board Mounting Screw
35 1034319 Remote Board Cover Mounting Screw
36 1033584 Logotype Plate
8 1033646 Mini Clamp B
9 1034261 Mini Clamp B Mounting Screw
2 1034024 Optical Engine
2-1-13 1031985 ELP5000 Lamp
2-19 1031941 ELP5000 Lens Cap
23 3002143 Main Board Assembly
24 1021795 Filter Board B Mounting Screw
4 2023402 Power Supply Block
5 1021824 Mounting Screw
6 1033692 Power Supply Block Mounting Screw
7 2023440 Cable Assembly I
51 4006463 User’s Manual Set
52 1032303 Seal Set
53 2017328 AC Power Cable
54 2016048 A.V. Cable (RCA Plugs)
55 1033569 ELP5000 Remote Control
56 2023359 Mac Adapter Set
57 2022604 Computer Cable (VGA Cable)

Epson PowerLite 5000 Specifications

General

Brand	Epson
Model	PowerLite 5000
Category	Projector
Language	English
