EPSON PowerLite 5000 Service Manual
3-29
3.2.22 Removing the FC Board
Prerequisite conditions: 3.2.3/3.2.4/3.2.8/3.2.13/3.2.17
Figure 3-38
1. Disconnect cable connector CN1 from the FC board.
2. To detach the FC board, remove the screw.
FC Board
Screw
