EPSON PowerLite 5000 Service Manual
A-1
A.1 Parts List
The following table shows the parts that are available for the projector*. Appendix B of
this manual, which contains the schematic diagrams for the projector, is available
separately. (The part number is listed in the table below.)
Table A-1
Reference No: Part No.: Description:
1 1031924 Lower Case Block
1-1 1031925 Lower Case Unit
1-1-1 1032096 Board Guide Sheet
1-1-10 1034026 Foot Case Mounting Screw
1-1-11 1032042 Foot Adjuster B
1-1-12 1034023 Stop Ring C
1-1-13 2023443 Filter Cover Switch Unit
1-1-14 1032043 Air Filter Frame Unit
1-1-15 1032046 Lamp Cover Unit
1-1-16 1032344 Handle
1-1-17 1021809 Handle Holder
1-1-18 1033021 Mini Clamp
1-1-2 1032070 Power Cable Shield Sheet
1-1-3 1034248 Filter Board Insulation Plate
1-1-4 1032027 Foot Adjuster A Unit
1-1-5 1032032 Foot Case
1-1-6 1032036 Foot Holder
1-1-7 1032037 Foot Pipe
1-1-8 1032039 Foot Spring
1-1-9 1032580 Stop Ring D
1-10 1034249 Filter B Insulation Plate
1-11 1021824 Mounting Screw
1-12 1021795 Filter Board B Mounting Screw
1-13 2023443 Filter Cover Switch Unit
1-14 1032043 Air Frame Filter Unit
1-15 1033581 Remote Board Shield Plate B
1-16 1034251 Shield Film
1-2 2024028 Connector Board Cable Assembly
1-2-1 3002149 Connector Board Assembly
1-3 1033703 Connector Board Mounting Screw
1-4 2023617 AC Cable Assembly
1-5 1032049 AC Inlet Holding Plate
1-6 1021824 Mounting Screw
1-7 1033025 GND Cable Mounting Screw
1-8 2023618 Filter Board Assembly A
1-9 1032753 Filter B Holding Plate
10 1032050 Case Holding Plate
11 1034260 Sensor Insulate Plate
12 1021795 Filter Board B Mounting Screw
13 1033691 Cable Assembly G Mounting Screw
14 1034027 Washer
15 1032051 Speaker Block
15-1 1032052 Speaker Holding Plate
