EPSON PowerLite 5000 Service Manual
1-17
VIDEO INPUT/OUTPUT
Computer In 1 interface
Computer In 2 interface
Host computer 1 RGB output
Interface type: HD-15-pin (DDC1/2B compatible)
S-Video Interface Input signal: Luminous 0.714 Vp-p, Chrominous 0.28 Vp-p.
Interface type: Min-DIN 4-pin
S-Video is prior to composite video.p.
Video IN Interface
(Composite video interface)
Input signal: 1,0 Vp-p, sync, negative
Interface type: RCA jack (yellow)
TV signal type: NTSC 3.58 MHz
PAL 4.43 MHz
SECAM 4.43 MHz
Auto identification (default)
MOUSE/COM 1/2
Serial Mouse or RS-232C Auto identification (Mouse or RS-232C)
Interface type: 13-pin DIN
POWER SUPPLY
Input Voltage 100 – 120 VAC /220 – 240 VAC ± 10% (50/60 Hz)
Power Consumption Approximately 240 W (standby mode: 30 W)
Dimensions 9.7 (W) x 5.5 (H) x 12.4 (D) inches
(245 (W) x 140 (H) x 316 (D) mm)
9.7 (W) x 6.3 (H) x 15.0 (D) inches including foot
adjuster and lens (245 (W) x 159 (H) x 380 (D) mm)
Weight Approximately 14.1 lb (6.4 kg)
ENVIRONMENT
Operational/ storage temperature +39°F ~ 104°F/ +14°F ~ 140°F
(+5°C ~ +40°C/ -10°C ~ +60°C) (non condensing)
Operational/ storage humidity 20%~ 80% / 10%~ 90% (non condensing)
Operational/ storage altitude 10,000 feet (3048 m) / 20,000 feet (6096 m)
