SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 169
Confidential
13. Remove the PF TIMING BELT.
Figure 3-122. Removing the PF TIMING BELT
PF TIMING BELT
