4.15.4 Motor Measurement & Automatic Adjustment
The measurement adjustment can be made for the following motors individually.
 CR MOTOR
 Pump motor (PUMP CAP UNIT)
 PF MOTOR
 ATC MOTOR
 Cutter motor
EXECUTION MODE
Normal mode
PROCEDURE
1. Turn the printer ON.
2. Start the Service Program and select Motor Measurement & Automatic
Adjustment of the target motor.
3. Click [Run].
Measurement and adjustment are performed automatically.
4. When finished, click [Finish].
5. Turn the printer OFF to finish the adjustment.
Figure 4-80. [Motor Measurement & Automatic Adjustment] Screen
C A U T I O N
If the adjustment is not finished, replace the motor.
