SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT Media Feed Related Checks and Adjustments 267
Confidential
4.13.5 Paper Thickness Sensor Adjustment
REQUIRED TOOLS
Adjustment jig for paper thickness sensor (0.5/0.6/0.8/1.0)
EXECUTION MODE
Serviceman Mode
STANDARD VALUE
CHECKING PROCEDURE
1. Remove the following part in advance.
TOP COVER (P. 85)
2. Attach the control panel (P. 120) with the upper rear cover removed.
3. Turn the printer ON in the Serviceman Mode. Turn the power ON while pressing
[Menu] + [Back] + [OK].
4. Select Mecha Adjustment Paper.
5. Press [Paper Set], and lock the paper presser.
6. Check that the control panel displays “00”. When the displayed value is other than
“00”, carry out the adjustment. Go to ADJUSTMENT PROCEDURE.
7. Press [Paper Set], and release the paper presser.
8. Insert the adjustment jig of 0.5 from the paper insertion opening and set the jig at
the position shown in Figure 4-66, then press [Paper Set].
9. Check that the control panel displays “00”. When the displayed value is other than
“00”, carry out the adjustment. Go to ADJUSTMENT PROCEDURE.
10. Press [Paper Set], and release the paper presser.
11. Set the adjustment jig of 0.6 at the position shown in Figure 4-66, then press
[Paper Set].
12. Check that the control panel displays “10”. When the displayed value is other than
“10”, carry out the adjustment. Go to ADJUSTMENT PROCEDURE.
13. Press [Paper Set], and release the paper presser.
14. Set the adjustment jig of 0.8 at the position shown in Figure 4-66, then press
[Paper Set].
15. Check that the control panel displays “10”. When the displayed value is other than
“10”, carry out the adjustment. Go to ADJUSTMENT PROCEDURE.
16. Press [Paper Set], and release the paper presser.
17. Insert the adjustment jig of 1.0 from the paper insertion opening and set the jig at
the position shown inFigure 4-66, then press [Paper Set].
18. Check that the control panel displays “11”. When the displayed value is other than
“11”, carry out the adjustment. ADJUSTMENT PROCEDURE.
19. Press [Paper Set], and release the paper presser.
Table 4-11. Standard Value
Paper presser status Jig type Panel display
Locked N/A 00
Locked 0.5 00
Locked 0.6 10
Locked 0.8 10
Locked 1.0 11
Released N/A 01
