SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
MAINTENANCE Cleaning 285
Confidential
5.5 Cleaning
CLEANING THE ROLLER
1. Turn the printer on and load a roll paper with the specified maximum width.
2. Press the [Feed/Cut Media] button, then press the [Down] button.
CLEANING THE PLATEN
1. Open the Printer Cover.
2. Wipe of the dust or dirt in the direction of the arrow using a soft cloth such as a
waste cloth. If the dirt persists, damp a soft cloth in water with a little neutral
detergent and wring it out tightly, then wipe the dirt off with it, then dry the platen
with a dry soft cloth.
Figure 5-3. Cleaning the Platen
C H E C K
P O I N T
The roll paper will be fed while the [Down] button is pressed. If no
smear is attached on the roll paper, it is the end of cleaning, so stop
cleaning the roller.
C A U T I O N
Do not touch the ink pads.
Ink pad
Platen
To Next Page
