SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT NV-RAM BACKUP/NVRAM Viewer 222
Confidential
4.2.3 NVRAM Viewer Basic Operation
The following functions are provided.
1. Displays the Life Parts Operation History
2. Displays the history how the printer has been used (Utilization History)
3. Displays the Error History saved in the NVRAM
4. Displays the Basic Information of the printer (such as the serial No. or the
setting values)
PROCEDURE
1. Click [Display Information] on the NVRAM Read field of the NV-RAM
BACKUP screen. Another screen of the NVRAM Viewer will be displayed.
2. Select the tab you want to check.
3. Click [Save as CSV] to save the information shown in the selected tab as CSV
file.
4. Click [Print] to print the information shown in the selected tab.
5. Click [Close] to close the screen.
DESCRIPTION
 Life Parts Operation History
Figure 4-3. [Life Parts Operation History] Screen
1 Total Print Dimension Total printed area. The unit is m
2
.
2 Items ---
3 Current Value Displays current values for each part or unit.
4 Limit Displays the life limit of the part if it has.
5 Situation
Displays the percentage of Current Value (3) considering
the Limit (4) as 100%.
6
End of Life Estimation (YY/
MM/DD)
The estimated date when the part or unit reaches the end of
its service life.
1
2
3
4 5 6
To Next Page
