Epson SC-T7000 series User Manual

SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT Overview 201
Confidential
CR related
parts/units
CR UNIT (CR Assy)
After
replacement
14
PW + T&B&S check and adjustment √
Matte paper
√ ---
p. 243
15
Cut Position check & adjustment √√---
p. 266
16
Reset the motor counter. √√---
p. 231
17
Housing Assembly --- √√
APG UNIT (APG Motor)
Replacement
1
---
p. 144
After
replacement
2
APG function check √√---
p. 237
3
Reset the motor counter. √√---
p. 231
IM SENSOR
Replacement
1
---
p. 159
After
replacement
2
PW + T&B&S check and adjustment √
Matte paper
√ ---
p. 243
3
Ink Mark Sensor check & auto adjustment √
PGPP
√ ---
p. 238
4
Cut Position Check & Adjustment √√---
p. 266
PW SENSOR
Replacement
1
---
p. 161
After
replacement
2
PW + T&B&S check and adjustment √
Matte paper
√ ---
p. 243
3
Ink Mark Sensor check & auto adjustment √
PGPP
√ ---
p. 238
4
Cut Position Check & Adjustment √√---
p. 266
CR ENCODER
Replacement
1
---
p. 138
After
replacement
2
CR Belt Tension Adjustment √
Tensimeter U-507
√√
p. 234
3
APG function check √√---
p. 237
4
CR Scale Check √√---
p. 239
5
CR Motor Measurement & Automatic
Adjustment
√√---
p. 279
6
CR Active Damper Adjustment (Automatic) √√---
p. 240
7
Head inclination auto adjustment (CR
direction)
√√---
p. 253
8
Head slant auto adjustment (PF direction) √√---
p. 256
9
Head inclination manual adjustment (CR
direction)
√√---
p. 254
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired (Reattached)
Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
