SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
PRODUCT DESCRIPTION Control Panel Specifications 28
Confidential
Paper menu
Load/Remove Paper
Remove Paper
Press the [OK] button to view instructions for removing the paper. Follow the on-
screen instructions to remove the paper.
Instructions are not displayed if no paper is loaded.
Roll Paper
Highlight the paper to be loaded and press the [OK] button. Follow the on-screen
instructions to load the paper.
If paper is already loaded in the printer, the instructions for removing the loaded
paper type will be displayed before loading instructions are shown.
Cut Sheet (up to 0.8
mm thick)
Poster Board
Select Paper Type
Photo Paper
Select the type of paper loaded.
Matte Paper
Plain Paper
Others
Custom Paper Select the name of the custom paper loaded in the printer.
Custom Paper
Setting
XXXXXXXXXXX
(name of custom
paper type)
Select Reference
Paper
Photo Paper
You can select the media type that is the closest to the paper you are using.
Matte Paper
Plain Paper
Others
No Paper Selected Select this option if you do not wish to specify the paper type.
Platen Gap
Narrow
Select the platen gap which is the distance between the print head and the paper.
Normally, select “Standard”. Select a wider setting if printed images are smeared. If,
upon performing head alignment you feel that it is still not completely aligned, select
“Narrow”.
Standard
Wide
Wider
Detect Paper
Thickness
Press the [OK] button to print a pattern to determine the thickness of the current paper.
Select the pattern number with the least misalignment from the print results.
Table 1-8. Menu List
Menu Menu Item / Setting Value (Shaded one is the default) Explanation
