SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
DISASSEMBLY & ASSEMBLY Parts Diagram 72
Confidential
Figure 3-3. Cover sensors
CARTRIDGE COVER SENSOR
(p. 106)
Detects the Open/Closed status of the
Cartridge Cover.
INTERLOCK SWITCH (p. 109)
Detects the Open/Closed status of the
PRINTER COVER.
R WASTE INK COVER SENSOR
(p. 107)
Detects the Open/Closed status of the
WASTE INK TANK COVER (R).
L WASTE INK COVER SENSOR
(p. 108)
Detects the Open/Closed status of the
WASTE INK TANK COVER (L).
