SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
DISASSEMBLY & ASSEMBLY Parts Diagram 77
Confidential
Figure 3-8. Auto Take-up Reel
TAKE-UP REEL COVER (p. 185)
TAKE-UP REEL
SENSOR (p. 186)
TAKE-UP REEL
SWITCH (p. 188)
TAKE-UP REEL
LED (p. 187)
TAKE-UP REEL
MOTOR (p. 192)
TAKE-UP REEL MAIN BOARD
(p. 194)
TAKE-UP REEL PS
BOARD (p. 190)
