Epson SC-T7000 series User Manual

SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
DISASSEMBLY & ASSEMBLY Disassembly Flowchart 81
Confidential
PAPER FEED MECHANISM / CUTTER
“3.4.2.8 UPPER SUPPORT R
COVER (p94)”
Start
“3.4.2.14 UPPER LEFT COVER
(p100)”
“3.4.2.1 TOP COVER (p85)”
“3.4.2.9 RIGHT UPPER COVER &
RIGHT ROLL COVER (p95)”
“3.4.2.2 FRONT COVER (p86)”
“3.4.3.7 PANEL BOARD (p120)”
“3.4.5.1 PF MOTOR (p163)”
“3.4.5.6 PRESSURE ROLLER
MOTOR (p171)”
“3.4.5.7 PRESSURE ROLLER
SENSOR (p173)”
“3.4.5.4 PF TIMING BELT
(p168)”
“3.4.2.15 LEFT UPPER COVER &
LEFT ROLL COVER (p101)”
“3.4.2.18 REAR LEFT LOWER
COVER (p104)”
“3.4.2.12 LEFT LOWER COVER
(p98)”
“3.4.5.3 PF ENCODER (p166)”
“3.4.5.2 PF SCALE (p165)”
“3.4.2.15 LEFT UPPER COVER &
LEFT ROLL COVER (p101)”
“3.4.2.3 LOWER PAPER GUIDE
(p87)”
“3.4.6.1 CUTTER UNIT (p181)”
“3.4.2.4 LOWER PAPER GUIDE B
(p88)”
“3.4.2.12 LEFT LOWER COVER
(p98)”
“3.4.2.10 RIGHT LOWER COVER
(p96)”
“3.4.2.17 FRONT LEFT LOWER
COVER (p103)”
“3.4.2.5 IH COVER (p89)”
“3.4.2.2 FRONT COVER (p86)”
“3.4.5.11 PAPER THICKNESS
SENSOR (p180)”
“3.4.5.8 ATC MOTOR (p175)”
“3.4.2.19 REAR ROLL COVER
FRAME (p105)”
“3.4.5.9 PE SENSOR (ROLL
PAPER) (p177)”
“3.4.2.19 REAR ROLL COVER
FRAME (p105)”
“3.4.5.10 PE SENSOR (THICK
PAPER) (p178)”
“3.4.5.5 PRESSURE ROLLER
(p170)”
