Page #180 background imageLoading...
Page #180 background image
B-2
Printer Specifications
Printing
Paper
Note:
Since the quality of any particular brand or type of paper may be changed
by the manufacturer at any time, EPSON cannot attest to the quality of
any non-EPSON brand or type of paper. Always test samples of paper
stock before purchasing large quantities or printing large jobs.
Printing method On-demand ink jet
Nozzle configuration Monochrome (black) 64 nozzles
Color (cyan, magenta, yellow) 96 nozzles
(32 [each color]
×
3)
Resolution Maximum 1440 dpi
×
720 dpi
Print direction Bidirectional with logic seeking
Control code ESC/P Raster
EPSON Remote
Input buffer 32 KB
