Stylus Pro 4880 Field Repair Guide 1/17/08
Ink Bay Removal (Right) Printer Component, Software Item, LCD Display, Printer Button Page 61.
6. Remove 4 Screws and 2 Brackets
7. Remove 2 Screws from the front.
1 Screw on the
left Side
1 Screw and Bracket
on the left side
1 Screw and Bracket
on the right side
1 Screw on
the right Side.
2 Screws from the front
