Epson Stylus Scan 2000 Service Manual

EPSON Stylus Scan 2000
Revision A
Troubleshooting
Troubleshooting the Scanner
74
Table 3-11. Paper Feed Skewed
Cause Related Unit Check Method Solution
Paper guide is not set
correctly.
None
Check the pad
assembly.
Replace the pad
assembly and adjust
it.
Pad assembly is
wrong.
Pad Assembly
Check the pad
assembly.
Replace the pad
assembly and adjust
it.
Dust on the roller. Roller Visual Check
Wipe off the roller
with alcohol.
Paper is not set
correctly.
Operational Error
Check if the paper is
set correctly on the
paper support or slide
guide.
Teach the user the
right paper loading
position.
Paper is wrong. Operational Error
Check if the user uses
the specified paper.
None
Motor connector is
wrong.
None Visual Check
Connect the
connector.
Table 3-12. Abnormal noise/shaking
Cause Related Unit Check Method Solution
Paper is not set
correctly.
Operational Error
Check if the paper is
set correctly on the
paper support or slide
guide.
Teach the user the
right paper loading
position.
Paper is wrong. Operational Error
Check if the user uses
the specified paper.
None
Motor Unit is wrong. Motor Unit
Replace the motor
unit.
Replace the motor.
The connection with
motor is wrong.
None Visual Check
Connect the
connector.
MAIN Board is
wrong.
B101 MAIN Board Tester Check
Replace the MAIN
Board.
