EPSON Stylus Scan 2000
Revision A
Disassembly & Assembly
Disassembly Procedures
98
4.2.3.2 Removing the B101 PSB/PSE board
Follow the steps in Section 4.2.3 to remove the circuit board tray from the Stylus Scan. To
remove the B101 PSE/PSB board from the tray, refer to Figure 4-5 in the previous section
and remove:
n The cable (CN10) that connects to the MAIN Board
n The cable (CN1) that connects to the power cord
n Four screws (CBS 3x6) securing the board
n One screw (CBS 3x6) securing the ground
Be sure to perform the following adjustments when the MAIN Board
is replaced;
1. Head voltage ID Input (Refer to Chapter 5.)
2. Bi-D adjustment (Refer to Chapter 5.)
