A Rear cover Remove when removing jammed paper.
B USB port Connects a USB cable.
C AC inlet Connects the power cord.
D LINE port Connects a phone line.
E EXT. port Connects external phone devices.
Control Panel
Buttons and Lights
A Turns the printer on or o.
Unplug the power cord when the power light is o.
B Displays the home screen.
C Enter the last dialed number or enter a pause when entering a fax number.
D Stops the current operation.
E - Displays menus and messages.
User's Guide
Printer Basics
14
