67 / 106
7 • Description of socket hardware
80113-101_V25087
2023-11
Socket module NE 6 and NE 2-pin
Fig. 7-6
REF No. 20140-642
You may connect ONE of the following plugs: Erbe neutral electrode plug with Ø 6.35
mm; neutral electrode plug with 2
pins. The socket is equipped with a slide switch that
allows you to connect the plug with Ø
6.35 mm or the plug with 2 pins based on the
position of the socket (see illustration above).
