DRY CUT
Properties
Intense hemostasis with somewhat slower cutting speed.
Areas of use
All cutting procedures that require very good primary hemostasis during the cut and
tolerate a somewhat slower cutting process.
Suitable electrodes
Needle electrodes, knife electrodes, spatula electrodes.
Technical data
HF voltage waveform pulse-modulated sinusoidal alternat-
ing voltage
Rated frequency 540 kHz (at R
L
= 500 Ω) ± 10 %
Crest factor 2.4 (at R
L
= 500 Ω)
Rated load resistor 500 Ω
Max. HF peak voltage 900 Vp
HF power limitation VIO 50 C: 1 watt to 50 watts in 1 watt
steps
VIO 100 C: 1 watt to 100 watts in
1
watt steps
Max. power output at rated load resis-
tor
VIO 50 C: 50 watts ± 20 %
VIO 100 C: 100 watts ± 20 %
Max. RMS current (maximum HF output
current in normal use)
VIO 50 C: 200 mA
VIO 100 C: 330 mA
