Managing Hardware with CLI Commands
Determining Operating Status 5-23
Redback Approved State of transceiver testing for this SFP optical transceiver in SmartEdge routers:
• No—Redback
®
has not tested.
• Yes—Redback has tested.
RxPwrMin[dbm]
RxPwrMax[dbm]
2
–nn.nn—Receiver sensitivity (minimum) and overload level (maximum) for the version of the SFP transceiver
installed in this port.
S3Fpga rev S3 FPGA revision and file revision; applicable to XCRP only. This FPGA manages the control and phase
alignment of the Stratum-3 PLL.
SAR Image Type ATM mode currently loaded; applicable to second-generation ATM OC cards only:
• atm-priority—ATM priority mode.
• ip-priority—IP priority mode.
• vc-fair—Virtual circuit (VC) fairness mode.
SAR Image Version n.n.n.n—Version of the image.
SARC memory nnn MB—Size of segmentation and reassembly (SAR) controller (SARC) memory; applicable to ATM traffic
cards only.
SARC status Status of the segmentation and reassembly controller (SARC):
• OK—SARC is ready.
• Not Ready—SARC is not ready.
• Unknown—Unable to read SARC status.
SCC id ID for the system communication controller (SCC) ASIC on a controller card; the SCC controls and
communicates with the traffic cards.
Serial No nnnnnnnnnnnnnn—Unique identifier for this unit; 14 alphanumeric characters.
SFP / Media Type Version and cable type for the SFP transceiver installed in this port:
• CWDM / SM—Coarse wavelength-division multiplexing (CWDM) transceiver, single mode fiber.
• DWDM / SM—Dense wavelength-division multiplexing (DWDM) transceiver, single mode fiber.
• LX / SM—Long reach transceiver, single mode fiber.
• SX / MM—Short reach transceiver, multimode fiber.
• T / Cat5—Copper-based transceiver.
• ZX / SM—Extended long reach transceiver, single mode fiber.
SFP Serial No nnnnnnnnnn—Unique identifier for this transceiver; 10 alphanumeric characters.
Slot • slot—Slot number for this unit.
• N/A—No slot number for this unit.
SpiFpga rev
SpiFpga file rev
Security parameter index (SPI) FPGA revision and file revision; N/A or not displayed if not applicable for this
card.
SXC id ID of the SONET cross-connect (SXC) ASIC on a controller card; the SXC cross-connects traffic between
some traffic cards.
SysCPLD rev System CPLD version; applicable to the XCRP4 Controller card only.
SysFpga rev System FPGA revision and file revision; N/A or not displayed if not applicable for this card.
Temperature Temperature condition and actual temperature reading in degrees Celsius:
• Cold—Temperature is colder than normal.
• Extreme—Temperature is much hotter than normal.
• Hot—Temperature is hotter than normal.
• N/A—Temperature does not apply to this unit.
• Normal—Temperature is within normal operating range for this unit.
See Table 5-28 for temperature ranges for each condition.
Table 5-27 Output Fields for the show hardware Command with the detail Keyword (continued)
Field Description
