Managing Hardware with CLI Commands
5-22 SmartEdge 1200 Router Hardware Guide
Hardware Rev n—Hardware revision level for this unit; single digit.
HubFpga rev
HubFpga file rev
Hub FPGA revision and file revision; N/A or not displayed if not applicable for this card.
IPPA memory nnn MB—Size of ingress PPA memory.
ITU ch International Telecommunication Union (ITU) channel number (corresponds to the wavelength displayed in
the Wavelength field); not displayed if not applicable for the transceiver installed in this port.
LEDs State of the Fail, Active, Standby, and Sync LEDs:
• Blink—ODD test is in progress.
• On—LED is lit.
• Off—LED is not lit.
Sync LED is for controller cards only.
LimFpga rev LIM FPGA revision and file revision; N/A or not displayed if not applicable for this card.
MAC Address nn:nn:nn:nn:nn:nn—Medium access control (MAC) address of the system (stored in the EEPROM); displayed
only if you specify the backplane keyword.
Max2Fpga rev Max2 FPGA revision and file revision; applicable to XCRP3 only. This FPGA controls address translation.
MaxFpga rev Max FPGA revision and file revision; applicable to XCRP only. This FPGA controls access to the CPU bus.
Memory Memory for which this controller card is entitled:
• Max—All memory on the controller card is enabled.
• nnnn GB—Size in GB of enabled memory.
Mfg Date dd/mm/yyyy—Date unit was manufactured.
ODD Status Status of the ODD tests:
• Aborted—The session was terminated by the user or by the standby controller card being removed.
• Incomplete—At least one of the requested tests could not be run.
• In-progress—Session is currently in progress.
• Not available—No session of the ODD has been run for this unit.
• Passed—All tests have passed.
• n Failure(s)—One or more tests have failed.
Opus2Fpga rev Opus2 FPGA revision and file revision; applicable to XCRP3 only. This FPGA manages peripherals such as
the front panel LEDs and the Craft 2 port.
OpusFpga rev Opus FPGA revision and file revision; applicable to XCRP only. This FPGA manages peripherals such as the
front panel LEDs and the Craft 2 port.
POD Status Status of the power-on diagnostic (POD) tests:
• Success—Unit passed all POD tests.
• Failure—Unit failed one or more POD tests.
Port n—Port number if hardware data is port specific; not displayed if not applicable for this card.
Ports Configurable Number of ports on this traffic card that have been specified as software configurable (ATM DS-3 card only).
Ports Entitled List of ports that are entitled on this traffic card:
• n1, n2, n3,...—Entitled ports.
• All—All physical ports on the traffic card are entitled.
Power Supply A1 Status
Power Supply A2 Status
Power Supply B1 Status
Power Supply B2 Status
• No Power—Power has failed or is disconnected.
• Normal—Power is being supplied by this source.
Table 5-27 Output Fields for the show hardware Command with the detail Keyword (continued)
Field Description
