8 CONFIGURATION MENU
0460 949 274
- 39 -
© ESAB AB 2015
8 CONFIGURATION MENU
Main menu → Configuration menu
This menu contains the following sub-menus:
• Language, see “Choice of language”, page7.
• Code lock, see “Code lock”, page39.
• General configuration, see “General configuration”, page40.
• Machine configuration, see “Machine configuration”, page44.
• Cable lengths, see “Cable lengths (applies only to LAF and TAF power sources)”, page
54.
• Maintenance, see “Maintenance”, page55.
• Measure–values filter factor, see “Measure–values filter factor”, page55.
8.1 Code lock
Main menu → Configuration menu → Code lock
When the lock function is activated and you are in the measure screen or fast mode menu, a
password (lock code) is required to exit from these menus.
Code lock is activated in the configuration menu.
8.1.1 Lock code status
In lock code status, you can activate/deactivate the lock function without deleting the existing
lock code in the event you deactivate the function. If no lock code is stored and you try to
activate the code lock, the keyboard is displayed for entering a new lock code.
To exit lock status.
When you are in the measure screen or the fast mode menu and the code lock is
deactivated, you can exit these menus without restrictions by press QUIT or MENU in order
to go to the main menu.
