ESAB A2 - Wire Feed Axis Configuration; Cold Wire Axis (ICE) Configuration

8 CONFIGURATION MENU
0460 949 274
- 45 -
© ESAB AB 2015
The following options can be selected:
• A2TFJ1
A2 tractor automatic welding machine for Submerged Arc Welding (SAW)
• A2TGJ1
A2 tractor automatic welding machine for Gas-Shielded Metal Arc Welding (GMAW)
• A6TFF1
A6 tractor automatic welding machine for Submerged Arc Welding (SAW)
• MTW600
A6 tractor automatic welding machine for Submerged Arc Welding (SAW)
• FREE 2 AXIS
Optional configuration for connecting 2 motors to the actuator board. One for wire feed
and one for travel motion.
• FREE 3 AXIS
Optional configuration for connecting external roller beds, positioners or linear axis as
well as for 2 motors to the actuator board. One for wire feed and one for travel motion.
8.3.2 Wire feed axis
The wire feed motor is set automatically according to the tables below.
A2TFJ1 A2TGJ1 A6TFF1 MTW600
Motor 5035 38 RPM 5035 68 RPM VEC4000 FHP258
Gear 1 49:1 49:1 156:1 24:1
Gear 2 1:1 1:1 1:1 1:1
Diameter feed rollers 49 mm 49 mm 49 mm 30 mm
Pulse sensor 28 ppr 28 ppr 32 ppr 28 ppr
Low manual speed 150 cm/min 150 cm/min 150 cm/min 150 cm/min
High manual speed 300 cm/min 300 cm/min 300 cm/min 300 cm/min
FREE 2 AXIS FREE 3 AXIS
Motor VEC 4000 VEC 4000
Gear 1 156:1 156:1
Gear 2 1:1 1:1
Diameter feed rollers 49 mm 49 mm
Pulse sensor 32 ppr 32 ppr
Low manual speed 150 cm/min 150 cm/min
High manual speed 300 cm/min 300 cm/min
8.3.3 Cold wire axis (ICE)
FREE 2 AXIS FREE 3 AXIS
Motor VEC 4000 VEC 4000
Gear 1 156:1 156:1
Gear 2 1:1 1:1
Diameter feed rollers 49 mm 49 mm
Pulse sensor 32 ppr 32 ppr
