5 Layers and Instruments | 58
No. Signal
Type
Position No. of
Strips
Height Axes Signal Con-
figuration
Analog at the
top
any customizible
per strip
scalable color, line
width, marker,
connection
type
Boolean in the
middle
any customizible
but for all
Booleans the
same
fix color, marker,
connection
only steps
Event at the
bottom
one customizible none color, marker,
connection
only samples
To see how you can use strips and define the signals list settings of the oscil-
loscope, watch our video Oscilloscope - Defining Strips and Signal List.
You can perform the following actions:
"To add another strip" on the next page
"To reorder strips" on the next page
"To move analog signals to a common or individual strip" on the next page
"To delete a strip" on page60
