5 Layers and Instruments | 66
4. Click the icon again. This has the following effect:
l
If both cursors have been in the visible area, they are hidden now.
l
If one of the cursors has been outside the visible area, it is displayed
now.
To delete cursors
1. To delete a specific cursor, activate it by right-click with the mouse.
2. Select Delete cursor inthe context menu.
or
1. To delete all cursors, even if not in the visible range, use CTRL+ALT+R.
To move a cursor sample-wise
By default, the cursors' movement mode is time-based. You can change the
movement mode to navigate a cursor from sample to sample. The selected mode
is valid for all cursors in the oscilloscope.
1. Select Switch to Sample-wise Navigation in the cursors' drop-down
menu or use the tab Instrument in the Properties window.
The cursor label changes into a round shape .
Depending on the location of the cursor, the cursor's line is shown as fol-
lows:
l
If the cursor is exactly on an existing sample, the cursor's line is solid.
l
If the cursor is in-between two samples, the cursor's line is dashed.
2. To move a cursor to another sample, hover over the blue line and drag it to
the new position. Alternatively, press ARROW LEFT orARROW RIGHT (the short-
cut keys apply to the active cursor).
The cursor jumps to the closest sample of the current timestamp. For nav-
igation, only samples of the currently active signals are considered. If no
signal is selected in the signal list, all samples from all signals are taken into
account.
If you move the cursor to a position where no sample is available, the tool-
tip next to the cursor label is marked in red indicating that the cursor can-
not be moved in this direction any further.
To anchor a cursor to a position in the visible range
By default, cursors have a fixed timestamp and a variable screen position. When
scrolling or zooming, the cursor moves with the signal curve. This means that the
cursor can move outside the visible range. To keep the cursor in the visible range,
you can anchor it.
1. Hover over the cursor label at the top of the cursor (A or B).
The character changes into an anchor symbol .
2. Click the anchor symbol.
The cursor is fixed to the screen position. The cursor label shows the
